Usage |
Hose diameter (") |
Length (m) |
Inlet thread ("bsp) |
Outlet thread ("bsp) |
Maximum pressure (bar) |
Weight (kg) |
|---|---|---|---|---|---|---|---|
Air / water |
1/2 |
15 |
1/2 |
1/2 |
20 |
24 |
|
Oil |
1/2 |
15 |
1/2 |
1/2 |
160 |
24 |
|
Grease |
1/4 |
15 |
1/4 |
1/4 |
400 |
26 |
|
Grease |
3/8 |
15 |
3/8 |
1/4 |
400 |
26 |
|
High prssure hot water |
3/8 |
15 |
3/8 |
1/4 |
170 |
26 |
For oil
Diameter: 1/2"
Length: 15m
Maximum pressure: 160 Bar
Inlet thread: 1/2" BSP
Outlet thread: 1/2" BSP
Weight: 24 kg
For grease
Diameter: 1/4"
Length: 15m
Maximum pressure: 400 Bar
Inlet thread: 1/4" BSP
Outlet thread: 1/4" BSP
Weight: 26 kg
For grease
Diameter: 3/8"
Length: 15m
Maximum pressure: 400 Bar
Inlet thread: 3/8" BSP
Outlet thread: 1/4" BSP
Weight: 26 kg
For high pressure hot water
Diameter: 3/8"
Length: 15m
Maximum pressure: 400 Bar
Inlet thread: 3/8" BSP
Outlet thread: 1/4" BSP
Weight: 26 kg
For air, water, diesel and oil.
Diameter: 1/2"
Length: 20m
Maximum pressure: 160 Bar
Inlet thread: 3/4" BSP
Outlet thread: 1/2" BSP
Weight: 36 kg
